Microscope Type                   Parallel Galilean

Magnification changer           Revolving the drum

Eyepiece                                12.5X

Total magnification                6X  10X  16X  25X  40X （10X  16X  25X  optional)

Diameter of Vision field        φ37  φ23  φ14  φ8.7  φ5.7(mm)

Pupil adjusting range             54 mm~82 mm

Diopter adjustment                -7D ~ +7D

Slit image width                     0mm～14mm continuous

Slit image length                   1mm～14mm continuous

Diameter of aperture            φ14mm、φ10mm、φ5mm、φ3mm、φ1mm、φ0.2mm

Slit angle                                0～180 Rota table continuous

Illumination tilting                   5、10、15、20 totally 4 step

Filter                                       Heat absorption, Grey, red free(Green), Cobalt blue

Illumination                            12v, 30w halogen bulb

Fixation                                 Red LED 3.5V

Power                                   Input voltage  100~240V

                                              Input frequency 48~62 Hz

                                              Input power 60VA

Dimension                          740*650*450mm   total 27kg

Package                             Carton
