Measurement Range

Sphere

Cylinder

Axis

ADD

Prism

Step: 0.12/0.25 D

+/- 25D (spectacle lenses)

+/- 25D (BC=6.00to 9.00 )

Contact  lenses

Step: 0.12/0.25 D

0 D ~ ± 10D

0 to 180

 ± 10D (Add and Ad2)

(0.12/0.25D increment)

0Δ to 15Δ (horizontal, vertical)

(0.12/0.25 Δ increments)

Features Of measurements

Auto detection and measurement of Progressive power lens, Automatic addition power measurement, CYL mode conversion function (+/- ), compensation of high index lenses.

Measureable Lens Diameter

5 to 100 mm

Measuring Time

0.1 sec ± 10% (minimum)

Measurable Transmittance

10%  and over (20 % and over for ± 15.0 D to ± 25.0D)

Wave length/

Measuring point

535 nm (Green) more than 100 points cluster through nose piece.

Display

Hi-resolution Color LCD with back light

Marking system

Pre-filled Ink Cartridge type pen ( more than 42000 impressions)

Power Source

AC 100V ± 10% to 240 V ± 10%     50/60Hz

Power consumption

40VA

Dimensions & weight

180( w) x 185(D) x 366(H) mm /3.5kg

Standard Accessories

Dust cover (x1), Power cord (x1), contact lens nosepiece (x1
